| COMPATIBILITY | |
| PRODUCT LIST | All Cameras with CFAST 2.0 memory card support. |
| GENERAL | |
| CAPACITY | 1 TB |
| FORM FACTOR | CFAST 2.0 | VIDEO PERFORMANCE GUARANTEE-230 (VPG-230) |
| DIMENSIONS | 1.69 × 1.43 X 0.13 INCH (42.8 × 36.4 × 3.3 MM) |
| WEIGHT | ~ 0.35 OZ | ~ 10.0 G |
| PERFORMANCE | |
| MAX READ SPEED | UP TO 565 MB/S |
| MAX WRITE SPEED | UP TO 450 MB/S |
| RELIABILITY | |
| MTBF | 2,000,000 hours |
| DATA RELIABILITY | BUILT-IN EDC | ECC FUNCTION |
| DATA RETENTION | 10 YEARS AT 25° |
| ENVIRONMENTAL CERTIFICATION | ROHS, CE, FCC |
| TECHNICAL | |
| OPERATING VOLTAGE | DC 3.3V (±5%) |
| INTERFACE | SATA 3.1 COMPLIANT |
| FEATURES | SMART | BUILT-IN EDC | ECC FUNCTION | TEMPERATURE SENSOR | TRIM | EMS PROTECTION | BUILT-IN CACHE |
| ENVIRONMENTAL | |
| SHOCK RESISTANCE | 50G |
| VIBRATION RESISTANCE | 3.3G |
| OPERATING TEMPERATURE | 23 TO 168°F (-5 TO 75°C) |
| STORAGE TEMPERATURE | 13°F TO 185°F (-25°C TO 85°C) |
| OPERATING HUMIDITY | 5 % TO 95 % NON-CONDENSING |
| WARRANTY | |
| 3 YEARS | TO RECEIVE THE FULL LIMITED WARRANTY, THE PRODUCT NEEDS TO BE REGISTERED ON EGODISK.COM |
QUALITY CONTROL
EGODISK DEEPLY UNDERSTANDS THAT QUALITY IS THE BASIC WEAPON FOR AN ENTERPRISE TO WIN. PRODUCTION IS CONDUCTED ACCORDING TO INTERNATIONAL STANDARDS. QUALITY CONTROL IS CARRIED OUT BY 80 INSPECTORS USING EQUIPMENT FROM THE US AND JAPAN. ALL RAW MATERIALS ARE INSPECTED TO MEET THE ROHS STANDARDS BEFORE THE PRODUCTION. OUR LONG-TERM, STRATEGIC, STABLE PARTNERSHIPS WITH KEY COMPONENT SUPPLIERS ENSURE PRODUCT QUALITY AND RELIABILITY. FOUR INSPECTION STAGES DURING PRODUCTION AND A FINAL PRODUCT TESTING PRIOR TO PACKING ENSURE OUR LOW DEFECTIVE.
VIBRATION TESTS ON FINISHED PRODUCT PACKAGE CASES AND SALT FOG TESTS ON METAL PARTS ARE CONDUCTED TO ENSURE QUALITY AND RELIABILITY. ALL PRODUCTS ARE CE, FCC CERTIFIED. THEY ARE ALSO COMPLIANT WITH THE ROHS DIRECTIVE, CPRM AND OTHERS.
TESTED UNDER EXTREME CONDITIONS
EGODISK HAS A PROFESSIONAL TESTING LIBRARY, ALL THE PRODUCTS APPROVED BY QUALITY LAB WITH 600 AND PLUS TESTING HOURS WHICH CAN GUARANTEE PERFORMANCE, QUALITY, COMPATIBILITY AND RELIABILITY AND OPERATION IN HARSH TEMPERATURE CONDITIONS FROM -13°F TO 185°F / -25°C TO 85°C.
PERFORMANCE
EGODISK CFAST 2.0 MEMORY CARD DELIVERS THE PERFORMANCE NEEDED FOR THE BROADCAST, CINEMA, AND PHOTOGRAPHY INDUSTRIES.
EGODISK COMBINES THE SPEED, CAPACITY, AND PERFORMANCE NEEDED TO RECORD UNINTERRUPTED DCI VIDEO, WHICH HAS A RESOLUTION OF 4K OR HIGHER. IT FEATURES A SATA 3.1 6 GB/S BUS, A MAXIMUM READ SPEED OF UP TO 565 MB/S, A MAXIMUM WRITE SPEED OF UP TO 450 MB/S, AND A MINIMUM WRITE SPEED OF 230 MB/S. ITS MINIMUM WRITE SPEED IS BACKED UP BY THE VIDEO PERFORMANCE GUARANTEE 230 STANDARD (VPG-230), MEANING THAT ITS MINIMUM WRITE SPEED WILL NEVER DROP BELOW 230 MB/S. THIS CARD HAS BEEN TESTED TO WORK IN TEMPERATURES OF -5 TO 160°F.
